Edition 2026/1 www.h2qpumps.com PRODUCT CATALOGUE
2 | H2Q catalogue H2Q Pumps & Products H2Q offers a broad and carefully selected product range with reliable solutions for every water-related application. The Model H2Q is a subtle nod to H₂O - water - which lies at the heart of our products and our vision. The assortment includes professional water pumps, submersible pumps, filtration products and complementary components designed for practical, efficient use in a wide variety of installations. H2Q products are widely used in water applications, drainage systems, well pumps, swimming pools, irrigation systems and general water management, supporting both residential and professional installations. Distinctive quality. Fair Pricing. H2Q Pumps & Products is a strong and distinctive brand within the water technology sector. As one of the private labels of Water Is Life Group, H2Q stands for high-quality products at a fair and competitive price. Innovation driven by market needs H2Q product specialists are continuously exploring new sustainable innovations and opportunities to develop products in-house. By introducing these solutions under the H2Q brand, we are able to respond quickly to evolving market demands and emerging water-related applications. H2Q is the smart choice for professionals seeking practical, quality products that make the real difference in water technology.
H2Q catalogue | 1 Water is life, We take care of it H2Q Pumps & Products – A trusted brand of the Water Is Life Group H2Q Pumps & Products is a well-established private label brand of the Water Is Life Group, with more than 10 years of experience in delivering reliable and accessible water technology. H2Q products are sold worldwide and used in a wide range of water-related applications, where quality, functionality and fair pricing are key. The H2Q Pumps & Products mission is clear: to make professional water technology accessible, without compromising on performance or reliability. About the Water Is Life Group The Water Is Life Group is a network of 13 innovative companies, all leading players in the field of water technology. The group operates across multiple water-related sectors, including water treatment, clean water and wastewater management, irrigation, water distribution and geothermal solutions. With decades of combined expertise and a strong focus on innovation and sustainability, the Water Is Life Group develops solutions to address the most urgent global water challenges. H2Q products are supplied in high-quality, professional packaging with multilingual information, designed to support installers and end users worldwide. Content Surface pumps page 2 Submersible pumps page 11 Accessories page 26 Hydrophore tanks page 32 Hoses and couplings page 33
| H2Q catalogue 2 SURFACE PUMPS SELF-PRIMING PUMPS Model Power Q (m3/h) 0 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0 3.3 Connection (inch) kW HP A Q (l/min) 0 5 10 15 20 25 30 35 40 45 50 55 Inlet Outlet H2Q JET 100S 0.75 1 5 H (m) 56 50.5 46 43 40 37.5 35 33 31 29 27 25 1" 1" Code Model N.W. (Kg) LxWxH (mm) A1.03.200 H2Q JET 100S 14.4 415×195×235 Equipped with 1,5 m cable and Schuko plug H2Q SELF-PRIMING JET PUMPS The H2Q JET pumps are self priming pumps designed to ensure reliability, power, and continuous operation in domestic and semi professional applications. Thanks to Jet technology, they can effectively draw water even in the presence of air bubbles, making them ideal for water supply from shallow wells, irrigation systems, and pressure boosting in domestic water networks. APPLICATIONS • Domestic water supply • Irrigation of gardens and vegetable plots • Pressure boosting in civil installations • Water lifting from shallow wells or storage tanks MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz • OPERATING CONDITIONS • Liquid temperature up to 60°C • Ambient temperature up to 40°C • Total suction lift up to 9m Components Construction Pump body: Cast iron Pump support: Aluminum Motor housing: Aluminum Impeller: AISI304 SS Diffuser: Techno-polymer Motor shaft: AISI304 SS Mechanical seal: Ceramic/Graphite Flow rate Q Head H (m)
H2Q catalogue | 3 SURFACE PUMPS SELF-PRIMING PUMPS H2Q PSPM70 INVERTER PUMP - STAINLESS STEEL The H2Q PSPm70 pump is an intelligent permanent-magnet, variable-speed pump designed to deliver constant pressure, quiet operation, and high energy efficiency in modern domestic applications. Thanks to its advanced technology and high-efficiency permanent-magnet motor, the pump automatically adapts to the system’s demand, ensuring a stable water supply under all operating conditions. Its compact and refined design makes it ideal for supplying water to an entire household, while keeping energy consumption low and maintaining exceptionally quiet operation. Integrated electronics, industrial grade sensors, and corrosion resistant materials ensure reliable performance even under challenging conditions, and the self priming capability allows for flexible installation in various domestic environments. APPLICATIONS • Domestic water supply with constant pressure • Irrigation of gardens and green areas, with automatic pressure adjustment • Pressure boosting in civil water networks with insufficient or variable flow • Water extraction from tanks or cisterns, supported by the self-priming function • Small businesses or commercial installations requiring quiet operation, comfort, and stable pressure OPERATING CONDITIONS • Suitable for pumping clean, low-viscosity, non-corrosive, non-flammable and non-explosive liquids, free from solid particles or fibres. • Maximum liquid temperature: 60 °C Model Power Q (m3/h) 0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 Connection (inch) kW HP A Q (l/min) 0 8 16 25 33 42 50 58 66 75 84 Inlet Outlet H2Q PSPm70 0.7 0,95 7.5 H (m) 42.5 41.8 40.5 39 37 35 32 28 19 1" 1" Code Model N.W. (Kg) LxWxH (mm) A1.62.300 H2Q PSPm70 7.58 371x190x289 Components Construction Pump body: PA6+GF30 Impeller: AISI304 SS Diffuser: Techno-polymer Motor shaft: AISI304 SS Mechanical seal: SAF MOTOR • Operation speed 2700 ~5000 rpm • Insulation Class F • Protection IP54 • Continuous service S1 • Single-phase 230V/50Hz Equipped with 1,5 m cable and Schuko plug H(ft) 12 0 4 8 0 84 58 42 25 m3/h 16 20 l/min PSP 8 75 24 28 32 36 40 44 48 40 13 0 26 52 65 78 92 105 118 131 16 33 50 66 1.0 1.5 2.0 2.5 0.5 3.0 3.5 4.0 4.5 5.0 Flow rate Q Head H (m)
| H2Q catalogue 4 No. Model Power A Q(m3/h) 0 1.2 2.4 3.6 4.8 6 7.2 8.4 9.6 10.2 Connection (inch) kW HP 1x230V 3x400 V Q(l/min) 0 20 40 60 80 100 120 140 160 170 Inlet outlet A H2Q HSP4-40 230 0.75 1 4.5 H (m) 45 42 37 31 22 1" 1" B H2Q HSP5-50 230 1 1.3 5.4 58 55 50 41 29 1" 1" C H2Q HSP9-50 230 1.35 1.8 7.5 52 50 48 45 42 36 29 21 12 7 1”1/4 1”1/4 D H2Q HSP9-60 230 1.65 2.2 9.5 65 64 61 57 52 45 37 27 16 10 1”1/4 1”1/4 E H2Q HSP9-70 400 2.1 2.8 3.8 78 76 73 69 62 54 45 33 20 12 1”1/4 1”1/4 Code Model N.W. (kg) L x W x H (mm) A1.03.300 H2Q HSP4-40 230 12.2 489×190×215 A1.03.302 H2Q HSP5-50 230 13.3 514×190×215 A1.03.304 H2Q HSP9-50 230 18.8 509×245×255 A1.03.306 H2Q HSP9-60 230 19.6 534×245×255 A1.03.308 H2Q HSP9-70 400 25 619×237×275 SURFACE PUMPS SELF-PRIMING HORIZONTAL MULTISTAGE PUMPS (LOW NOISE) H2Q HSP HORIZONTAL MULTISTAGE PUMPS The H2Q BMP series pumps are self-priming horizontal multistage pumps designed to deliver high efficiency, quiet operation, and consistent performance in both domestic and professional water pressurization applications The H2Q HSP pumps are designed with a cast iron pump body with stainless steel hydraulic components, a robust and long lasting solution that provides outstanding mechanical strength and excellent performance even under heavy duty conditions. APPLICATIONS • Domestic water supply • Garden and landscape irrigation • Pressure boosting in civil networks or small commercial installations • Rainwater recovery and boosting MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz • Three-phase 400V/50Hz Components Construction Pump body: Cast iron + SS Pump support: Cast iron Motor housing: Aluminum Impeller: AISI304 SS Motor shaft: AISI304 SS Mechanical seal: Ceramic/Graphite OPERATING CONDITIONS • Liquid temperature up to 60°C • Ambient temperature up to 40°C • Total suction lift up to 8m Single-phase models equipped with 1,5 m cable and Schuko plug Flow rate Q Head H (m)
H2Q catalogue | 5 SURFACE PUMPS SELF-PRIMING HORIZONTAL MULTISTAGE PUMPS (LOW NOISE) H2Q BMP HORIZONTAL MULTISTAGE PUMPS - BRASS / STAINLESS STEEL No. Model Power Q (m3/h) 0 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.0 7.2 8.4 9.6 10.2 Connection (inch) kW HP Q (l/min) 0 10 20 30 40 50 60 70 80 90 100 120 140 160 170 Inlet Outlet A H2Q BMP60-4 0.7 0.95 H (m) 40 39 35 31 25 18 10 1" 1" B H2Q BMP60-5 0.85 1.15 50 48 44 38 31 24 15 1" 1" C H2Q BMP90-4 0.85 1.15 44 43 41 3936332924 7 9 1" 1" D H2Q BMP90-5 1.05 1.4 53 52 51 49 45 41 36 30 23 13 1" 1" E H2Q BMP120-5 1.65 1.3 60 59 58 56 53 50 46 42.5 37 31 24 10 1" 1/4 1" F H2Q BMP170-4 1.4 1.85 50 49.3 48.5 47.5 46 44 43 40 38 35 32 25 17 9 5 1" 1/4 1" 1/4 G H2Q BMP170-5 1.65 2.2 62 61 60 59 58 56 54 52 48 45 42 34 25 15 10 1" 1/4 1" 1/4 Code Model Pump Packaging N.W. (Kg) LxWxH (mm) G.W. (kg) LxWxH (mm) A1.03.975 H2Q BMP60-4 10.6 406×154×174 11.3 500x210x240 A1.03.980 H2Q BMP60-5 11.7 430.5×154×174 12.4 500x210x240 A1.03.985 H2Q BMP90-4 11.7 406×154×174 12.4 500x210x240 A1.03.971 H2Q BMP90-5 13.2 430.5×154×174 13.9 500x210x240 A1.03.990 H2Q BMP120-5 17.6 460.5×154×174 18.3 500x210x240 A1.03.973 H2Q BMP170-4 17.5 437×178×200 18.2 500x210x240 A1.03.974 H2Q BMP170-5 19.1 461.5×178×200 19.8 500x210x240 The H2Q BMP series pumps are self-priming horizontal multistage pumps designed to deliver high efficiency, quiet operation, and consistent performance in both domestic and professional water pressurization applications. The brass pump body, suitable for potable water applications, ensures outstanding corrosion resistance, hygiene, and long service life, while the stainless steel components further enhance overall reliability even under intensive use. APPLICATIONS • Domestic water supply • Potable water systems • Garden and landscape irrigation • Pressure boosting in civil networks or small commercial installations • Rainwater recovery and boosting, supported by self priming capability and construction compliant with European water reuse standards Components Construction Pump body: Brass + SS Impeller: AISI304 SS Motor body: Aluminum Mechanical seal: Graphite,silicon carbide, NBR, AISI304 Motor shaft: Steel + AISI316 SS L H W m /h 3 l/min 10 20 30 40 50 60 70 80 90 100 110 130 140 150 160 180 120 170 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.0 6.6 7.8 8.4 9.0 9.6 10.8 7.2 10.2 H(ft) BMP 0 98 33 65 131 262 164 230 197 A B E G F D C Flow rate Q Head H (m) MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz
| H2Q catalogue 6 H2Q BMP-PC MULTISTAGE CONTROL PUMPS The H2Q BMP PC series pumps are self-priming horizontal multistage pumps already equipped with a presscontrol, offering a ready to use solution that simplifies installation and ensures automatic and safe system operation. Thanks to the presscontrol, the H2Q BMP PC pumps start automatically when water demand is detected and stop when there is no flow, providing practicality, dry run protection, and greater convenience during installation. APPLICATIONS • Pressure boosting for homes and buildings • Rainwater harvesting and reuse systems • Garden irrigation and outdoor watering • Clean water transfer MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz Code Model Pump Packaging N.W. (Kg) LxWxH (mm) G.W. (Kg) LxWxH (mm) A1.03.950 H2Q BMP60-4 PC 11,9 406×220×338 12,6 475×255×285 A1.03.955 H2Q BMP60-5 PC 13,5 430.5×220×338 14,2 475×255×285 A1.03.960 H2Q BMP90-4 PC 12,9 406×220×338 13,6 475×255×285 A1.03.965 H2Q BMP90-5 PC 14,2 430.5×220×338 14,9 475×255×285 No. Model Power Q(m3/h) 0 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 Connection (inch) KW HP Q(l/min) 0 10 2030405060708090 Inlet Outlet A H2Q BMP60-4 PC 0.70 0.95 H (m) 40 39 35 31 25 18 10 1" 1" B H2Q BMP60-5 PC 0.85 1.15 50 48 44 38 31 24 15 1" 1" C H2Q BMP90-4 PC 0.75 1.0 43 42 41 39 36 33 28 24 17 9 1" 1" D H2Q BMP90-5 PC 1.0 1.3 53 52 51 49 45 41 36 30 23 13 1" 1" SURFACE PUMPS PUMPS WITH PRESSCONTROL m /h 3 l/min 10 20 30 40 50 60 70 80 90 100 110 120 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.0 6.6 7.2 H(ft) BMP-PC 0 98 33 65 131 164 A B D C 0. Flow rate Q Head H (m) Components Construction Pump body: Brass + SS Impeller: AISI304 SS Motor body: Aluminum Mechanical seal: Graphite,silicon carbide, NBR, AISI304 Motor shaft: Steel + AISI316 SS L H W H
H2Q catalogue | 7 SURFACE PUMPS SELF-PRIMING VERTICAL MULTISTAGE PUMPS (LOW NOISE) H2Q VSP VERTICAL MULTISTAGE PUMPS The H2Q VSP series pumps are self priming vertical multistage pumps designed to deliver high pressure, constant flow rates, and reduced energy consumption, while ensuring quiet and reliable operation. Their vertical configuration provides a compact footprint and guarantees optimal hydraulic stability, making these pumps particularly suitable for domestic and civil installations, as well as applications requiring high performance and continuous operation. Developed for pressure boosting, water distribution, and irrigation, the H2Q VSP pumps offer a versatile and efficient solution wherever energy efficiency, reliability, and low noise levels are essential. APPLICATIONS • Domestic and civil water pressure boosting • Water distribution systems requiring high pressure • Garden and landscape irrigation • Rainwater recovery and lifting • Applications requiring continuous operation and low noise levels A B C No. Model Power - Ampere Q(m3/h) 0 1.2 2.4 3.6 4.8 6 7.2 8.4 9.6 10.2 Connection (inch) kW HP 1x230 V 3x400 V Q(l/min) 0 20 40 60 80 100 120 140 160 170 Inlet Outlet A H2Q VSP 9-60 1 x 230 1.65 2.2 9.5 H (m) 65 64 61 57 52 45 37 27 16 10 1" 1/4 1" 1/4 A H2Q VSP 9-60 3 x 400 1.65 2.2 3.6 65 64 61 57 52 45 37 27 16 10 1" 1/4 1" 1/4 B H2Q VSP 9-70 3 x 400 2.1 2.8 4.4 78 76 73 69 62 54 45 33 20 12 1" 1/4 1" 1/4 C H2Q VSP 9-90 3 x 400 2.4 3.2 5.0 92 90 87 82 75 65 53 39 23 15 1" 1/4 1" 1/4 Code Model N.W. (kg) LxWxH (mm) A1.03.350 H2Q VSP 9-60 1 x 230 23.6 559×265×265 A1.03.352 H2Q VSP 9-60 3 x 400 23.6 559×265×265 A1.03.354 H2Q VSP 9-70 3 x 400 28.5 659×280×275 A1.03.356 H2Q VSP 9-90 3 x 400 32 684×280×275 Components Construction Pump body: Cast iron + Stainless steel Pump support: Cast iron Motor housing: Aluminum Impeller: AISI304 SS Motor shaft: AISI304 SS Mechanical seal: Ceramic/Graphite OPERATING CONDITIONS • Liquid temperature up to 60°C • Ambient temperature up to 40°C • Total suction lift up to 8m Single-phase models equipped with 1,5 m cable and Schuko plug Flow rate Q Head H (m) MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz • Three-phase 400V/50Hz
| H2Q catalogue 8 SURFACE PUMPS PERIPHERAL PUMPS H2Q PM PERIPHERAL PUMPS The H2Q Pm pumps are peripheral pumps designed to deliver high pressure, reliability, and low energy consumption in domestic and residential applications. Thanks to their peripheral hydraulic design, they are ideal for small systems that require good head performance with moderate flow rates. Easy to install and operate, the H2Q Pm pumps represent the perfect solution for small domestic pressure boosting systems, water supply from tanks, pairing with small pressure sets, and garden irrigation. APPLICATION • Domestic water distribution • Pressure boosting in small water networks • Water supply from tanks and cisterns • Pairing with small pressure boosting units (autoclaves) • Irrigation of gardens, vegetable plots, and small green areas MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector • Single-phase 230V/50Hz OPERATING CONDITIONS • Liquid temperature up to 60°C • Ambient temperature up to 40°C • Total suction lift up to 8m Components Construction Pump body: Cast iron, with AISI304 SS insert Pump support: Cast iron, with AISI304 SS insert Motor housing: Aluminum Impeller: Brass Motor shaft: AISI304 SS Mechanical seal: Ceramic/Graphite No. Model Power (in) - Ampere Q(m3/h) 0 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0 Connection (inch) kW HP A Q(l/min) 0 5 10 15 20 25 30 35 40 45 50 Inlet Outlet A H2Q Pm37 0.37 0.5 2.6 H (m) 35 30 25 20 15 10.5 6.5 3 1" 1" B H2Q Pm60 0.55 0.75 3.9 554943373023 17 12 8 5 1" 1" C H2Q Pm75 0.75 1 65 59 52 45 38 31 25 19 14 10 7 1" 1" Code Model N.W. (kg) LxWxH (mm) A1.03.400 H2Q Pm37 4.7 263×162×190 A1.03.402 H2Q Pm60 7.1 298×179×221 A1.03.404 H2Q Pm75 8 298×179×221 Flow rate Q Head H (m)
H2Q catalogue | 9 SURFACE PUMPS SWIMMING POOL PUMPS H2Q SPP SWIMMING POOL PUMPS The H2Q SPP series pumps are self priming centrifugal pumps designed for swimming pool water circulation and filtration, combining high performance with quiet and reliable operation. Equipped with a large capacity integrated prefilter, they effectively protect the hydraulic system by capturing leaves, sand, and other debris. Their self-priming capability up to 3 meters ensures easy start up even when the suction line is not completely filled with water, making these pumps ideal for residential installations and technical rooms where suction conditions are not perfectly flooded. H2Q SPP pumps stand out for their low noise level, easy maintenance, and their ability to handle large water volumes at low head, making them an excellent choice for domestic pools and small hospitality facilities APPLICATIONS • Filtration and recirculation of water in residential swimming pools • Systems with integrated prefilter for debris retention • Above ground and in ground pools • Applications requiring quiet operation, continuous service, and minimal maintenance • Filtration systems with high flow rates and low head MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Protection IP44 • Continuous service S1 • Thermal protector for single phase • Single-phase 230V/50Hz • Three-phase 400V/50Hz No. Model Power (P1) Ampere Q(m3/h) 0 3 6 9 12 15 18 21 24 27 30 Connection (mm) kW HP 1x230 3x400 Q(l/min) 0 50 100 150 200 250 300 350 400 450 500 Inlet Outlet A H2Q SPP 800 M 0.85 1.2 3.6 H (m) 12 11.5 10.9 10.2 9.3 8.1 6.6 48.5(50) 48.5(50) B H2Q SPP 1100 M 1.1 1.5 5 16 15.3 14.6 13.8 12.8 11.6 10.2 48.5(50) 48.5(50) C H2Q SPP 1500 M 1.5 2 7.8 17 16.7 16.4 15.9 15.3 14.6 13.6 12.3 11 9.5 7.6 48.5(50) 48.5(50) C H2Q SPP 1500 T 1.5 2 9.5 17 16.7 16.4 15.9 15.3 14.6 13.6 12.3 11 9.5 7.6 48.5(50) 48.5(50) D H2Q SPP 2200 M 2.2 3 3 20 19.5 18.8 18 17.2 16.2 15 13.8 12.5 11 9 48.5(50) 48.5(50) D H2Q SPP 2200 T 2.2 3 4 20 19.5 18.8 18 17.2 16.2 15 13.8 12.5 11 9 48.5(50) 48.5(50) Components Construction Pump body: Techno-polymer Pump support: Aluminum Motor housing: Aluminum Impeller: Techno-polymer Motor shaft: AISI304 SS Mechanical seal: Ceramic/Graphite Code Model N.W. (kg) L x W x H (mm) A1.03.500 H2Q SPP 800 M 9.1 590×230×295 A1.03.502 H2Q SPP 1100 M 10.7 590×230×295 A1.03.504 H2Q SPP 1500 M 15.2 620×230×295 A1.03.506 H2Q SPP 1500 T 15.2 620×230×295 A1.03.508 H2Q SPP 2200 M 16.1 620x230x295 A1.03.510 H2Q SPP 2200 T 16.1 620x230x295 OPERATING CONDITIONS • Liquid temperature up to 45°C • Ambient temperature up to 40°C • Total suction lift up to 8m • Self priming up to 3 meters Flow rate Q Head H (m)
| H2Q catalogue 10 SURFACE PUMPS SWIMMING POOL PUMPS H2Q QCC SAND FILTER SETS The H2Q QCC sets are complete sand filtration systems designed to provide efficient and consistent water cleaning for residential swimming pools up to 60 m³. Each kit combines a durable plastic sand filter with a reliable and quiet LEO pool pump, ensuring optimal circulation and excellent water quality with low energy consumption. The H2Q QCC kits include a 7 way valve, dedicated fittings and connections, and integrated thermal protection for enhanced operational safety. In addition, the pump is equipped with a plug featuring a ground fault circuit interrupter (GFCI), increasing safety during operation and making the system suitable for residential pool environments. Thanks to their complete configuration and ease of installation, the H2Q QCC sets offer a simple, dependable, and ready to use solution for pool filtration. APPLICATIONS • Filtration of residential swimming pools up to 60 m³ • Recirculation systems with integrated pump and filter • Compact solutions for above ground or in ground pools • Applications requiring simplicity, reliability, and minimal maintenance Code Model Description Pump G.W. (kg) LxWxH (mm) B8.05.215 H2Q-QCC 310 max. capacity 20m³ - 230V LEO XKP256 10.2 390X380X585 B8.05.216 H2Q-QCC 400 max. capacity 30m³ - 230V LEO XKP456 11.5 390X390X700 B8.05.217 H2Q-QCC 560 max. capacity 40m³ - 230V LEO XKP606 20 720X520X620 B8.05.218 H2Q-QCC 580 max. capacity 50m³ - 230V LEO XKP806 22 720X520X620 B8.05.219 H2Q-QCC 600 max. capacity 60m³ - 230V LEO XKP906 24 820X580X700 OPERATING CONDITIONS • Maximum water temperature: 35 °C No. Model Power Q(m3/h) 036 9121518 Connector size (mm) Tank capacity Sand content kW HP Q(l/min) 0 50 100 150 200 250 300 A H2Q-QCC 310 0.25 0.34 H (m) 7.4 6.5 3.4 32/38 flexible hose Max. 20m³ 16 kg B H2Q-QCC 400 0.45 0.6 10.3 9.6 7.5 4.1 32/38 flexible hose Max. 30m³ 28 kg C H2Q-QCC 560 0.55 0.75 10.6 10.1 8.8 6.9 5.8 3 50 hard pipe 32/38 flex. hose Max. 40m³ 60 kg D H2Q-QCC 580 0.9 1.2 12.1 11.9 11 9.8 7.8 3.1 1.8 50 hard pipe 32/38 flex. hose Max. 50m³ 60 kg E H2Q-QCC 600 0.9 1.2 14.5 14.1 13.1 11.7 9.6 7 3.5 50 hard pipe 32/38 flex. hose Max. 60m³ 100 kg Components Construction Pump body: Techno-polymer Pump support: Techno-polymer Motor support: Aluminum Impeller: Techno-polymer Motor shaft: AISI304 SS Mechanical seal: Carbon/Ceramic/NBR 0 3 6 9 12 15 18 21 24 2 4 6 8 10 12 14 16 0 10 20 30 40 50 0 50 100 150 200 250 300 350 400 H(ft) m3/h l/min A B C D E Flow rate Q Head H (m)
H2Q catalogue | 11 H2Q OWP SUBMERSIBLE PUMPS The H2Q OWP pumps are compact submersible pumps designed for clean water handling in residential and light duty applications. Their construction ensures durability, corrosion resistance and reliable operation even in continuous duty conditions. Thanks to their quiet, efficient motor and easy installation, they provide a dependable solution for domestic water transfer, small irrigation systems and tank drainage. The OWP-SE version features an integrated electronic control that provides dry run protection, overpressure protection and automatic start/stop. This smart functionality enables fully autonomous water management, delivering maximum convenience and safety wherever hands free operation is required. APPLICATIONS • Domestic water transfer and supply • Garden and small area irrigation • Tank, open well, cistern and basement drainage • Automatic systems (OWP SE): autonomous on/off water management MOTOR • Two-pole induction motor (n = 2850 rpm) • Insulation Class B • Protection IP68 • Continuous duty S1 • Built-in thermal protector • Single-phase: 230 V / 50 Hz No. Model Power - Ampere Q(m3/h) 0 0.6 1.2 1.8 2.4 3 3.6 4.2 4.8 5.4 6 6.6 Connection (inch) kW HP A Q(l/min) 0 10 20 30 40 50 60 70 80 90 100 110 Outlet A H2Q OWP 1000S 1 1.4 4.5 H(m) 35 34 33 32 31 29.5 27 24 21 17 13 9 1” B H2Q OWP 1200S 1.2 1.6 5.5 45 44 43 42 40 37.5 35 32 28 24 20 16 1” A H2Q OWP 1000SE 1 1.4 4.5 35 34 33 32 31 29.5 27 24 21 17 13 9 1” B H2Q OWP 1200SE 1.2 1.6 5.5 45 44 43 42 40 37.5 35 32 28 24 20 16 1” Components Construction Pump body: Techno-polymer and AISI 304 SS Suction filter: AISI 304 SS Impeller: Techno-polymer Motor shaft: AISI 304 SS Mechanical seal: Ceramic / Graphite Code Model G.W. (kg) LxWxH (mm) A1.14.600 H2Q OWP 1000S 9.8 295×200×545 A1.14.602 H2Q OWP 1200S 10.2 295×200×570 A1.14.610 H2Q OWP 1000SE 9.8 295×200×570 A1.14.612 H2Q OWP 1200SE 10.2 295×200×590 SUBMERSIBLE PUMPS SUBMERSIBLE PRESSURE PUMPS Equipped with 20 m cable and Schuko plug OWP - S OWP - SE Flow rate Q Head H (m) OPERATING CONDITIONS • Maximum immersion depth: 8 m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C S - Float Switch / SE - Electronic control
| H2Q catalogue 12 SUBMERSIBLE PUMPS SUBMERSIBLE PRESSURE PUMPS H2Q COM SUBMERSIBLE RAINWATER PUMPS WITH PUMP CONTROL The H2Q COM and COM-X submersible pumps are 4" automatic multistage pressure pumps designed for domestic water supply, rainwater harvesting, irrigation and pressure boosting. They integrate advanced electronics directly inside the pump, eliminating the need for external controllers. APPLICATIONS • Domestic water supply and automatic pressure boosting • Rainwater collection and utilization systems • Irrigation, also from tanks and cisterns • Installation in 4" boreholes and underground reservoirs • Plug‑and‑play solutions for replacing traditional pressure‑boosting units • Pressure boosting in small private water networks KEY FEATURES • Integrated Electronic Control The pump starts automatically at 2.8 bar and stops when the water flow ceases, ensuring fully autonomous operation. • Advanced Dry Run Protection System The pump instantly stops when water is unavailable to avoid damage. It then performs automatic restart cycles at fixed intervals: • After 30 seconds → 3 restart attempts • After 1 hour → 3 attempts • After 5 hours → 3 attempts • After 24 hours → 3 attempts If water does not return, the pump remains safely shut down until conditions are normal again. • Leakage Detection If the pump detects more than 7 starts within 200 seconds, it stops automatically, signaling possible leakage or malfunction. • Integrated Non Return Valve Prevents backflow and ensures stable pressure in the system. • Automatic Air Bleeding Function Removes residual air from the hydraulic system, improving start up behavior and avoiding false dry run alarms. • High Quality, Corrosion Resistant Materials Stainless steel housing and robust internal components guarantee long term performance. • Self Cooling Motor The jacket cooled motor ensures cooling regardless of immersion depth. • COM X Version with side connection More practical for installations inside tanks or cisterns; also available in a version with a floating suction kit, ideal for drawing water from the cleanest surface layer MOTOR • Insulation Class B • Protection IP68 • Single-phase 230V/50Hz OPERATION CONDITION • Max. liquid temperature: 40 °C • Installation: vertical only (not suitable for horizontal installation) • Must be installed in combination with a water hammer arrestor Side suction (COM-X) Bottom suction (COM) COM-X with KIT Components Construction Pump casing: AISI 304 SS Motor casing: AISI 304 SS Impeller: Plastic POM Motor Shaft: AISI 304 SS Mechanical seal: Ceramic / Graphite
H2Q catalogue | 13 SUBMERSIBLE PUMPS SUBMERSIBLE PRESSURE PUMPS A B COM/COM-X Code Model Description Pump dimension Packaging Ø (mm) H (mm) G.W. (kg) LxWxH (mm) A1.14.500 H2Q COM 4" - 0.8 HP 0.8 HP submersible pump with built-in pump control, 80 l/min 98.4 738.8 11 950x130x130 A1.14.540 H2Q COM 4" - 1 HP 1 HP submersible pump with built-in pump control, 80 l/min 98.4 777.2 12 990x130x130 A1.14.510 H2Q COM-X 4" - 0.8 HP 0.8 HP submersible pump with built-in pump control and side connection 98.4 738.8 11 950x130x130 A1.14.515 H2Q COM-X 4" - 0.8 HP WITH KIT 0.8 HP submersible pump with built-in pump control and side connection including floating suction kit 98.4 738.8 - - No. Model Power Q(m3/h) 0 1 2 3 4 5 Connection (inch) kW HP Q(l/min) 0 17 33 50 67 83 Inlet Outlet A H2Q COM 4" - 0.8 HP 0.55 0.75 H(m) 48 41 38 31 24 15 - 1" B H2Q COM 4" - 1 HP 0.75 1 56 50 43 35 30 23 - 1" A H2Q COM-X 4" - 0.8 HP 0.55 0.75 48 41 38 31 24 15 1" 1" A H2Q COM-X 4" - 0.8 HP WITH KIT 0.55 0.75 48 41 38 31 24 15 1" 1" Equipped with 20 m cable and Schuko plug Flow rate Q Head H (m)
| H2Q catalogue 14 H2Q Q750 FLAT SUCTION PUMP WITH BUILT-IN SENSOR The H2Q Q750 is a compact and reliable submersible pump designed for clean water drainage in residential environments. Equipped with a durable motor, triple sealing and an oil filled chamber, it ensures dependable performance and a long service life. Its lightweight design and easy handling make it ideal for everyday domestic water removal tasks. The pump starts pumping at a water level of 50 mm and automatically stops at 5 mm, ensuring almost complete drainage—an important advantage when minimal residual water is required. A standout feature of this model is the integrated Aquasensor electronic control system, which replaces traditional mechanical float switches with precise water level detection supported by LED indicators. The Aquasensor allows the user to select exact start and stop levels, ensuring accurate activation even in narrow spaces where a float cannot operate. This makes the Q750 particularly suitable for tight shafts and shallow water conditions. In addition, the Aquasensor offers advanced delayed stop modes of 10 and 20 minutes, selectable directly from the control panel. These allow the pump to continue running after the water level falls below the stop point, ensuring complete drainage and preventing residual water accumulation—especially useful in basements and collection pits. APPLICATION • Automatic basement and pit drainage • Cisterns, tanks and open wells • Domestic water removal in utility areas and small pits • Hands free operation in tight space OPERATING CONDITIONS • Liquid temperature up to 35°C • Max. immersion depth 7m SUBMERSIBLE PUMPS FLAT SUCTION SUBMERSIBLE PUMPS Components Construction Pump body: PP - GF30 Motor winding: Aluminum Impeller: PA66 - GF30 Motor shaft: Carbon Steel Model Power Q(m3/h)0 2 4 6 8 1012 Solids passage Connection (inch) kW HP Q(l/min) 0 33 67 100 133 166 200 Outlet H2Q Q750 0.75 1 H (m) 8.5 7.5 6.6 5.5 4.4 3 1.2 5 mm 1" - 1" 1/2 Code Model Pump Packaging N.W. (kg) LxWxH (mm) G.W. (kg) LxWxH (mm) A3.02.255 H2Q Q750 5.36 237x172x300 5.56 270x230x360 0 2 4 6 8 10 12 14 1 2 3 4 5 6 7 8 9 0 0 33 H(ft) m3/h l/min 67 100 133 166 200 233 3 6 10 13 16 20 23 26 30 10 Q750 Flow rate Q Head H (m) MOTOR • Two-pole induction motor(n=2850 r.p.m) • Protection IPX8 • Single-phase 230V/50Hz Equipped with 10 m cable and Schuko plug
H2Q catalogue | 15 H2Q SPA530 FLAT SUCTION CONSTRUCTION SITE PUMP The H2Q SPA530 is a portable residue drainage pump designed for both professional users and DIY applications requiring fast, efficient and extremely low‑level clean‑water removal. It delivers long‑lasting reliability even under demanding site conditions. Thanks to its specially designed bottom plate, the pump begins operating from as low as 3 mm of water and can dry surfaces down to 1 mm, ensuring an almost completely dry finish. The swing check valve prevents back‑flow of the sucked water when the pump stops its operation. The SPA530 features a dry‑run tolerant, water‑cooled motor structure, proven by life tests showing continuous operation for up to 4 hours without water entering the pump. It also includes an abrasion‑resistant impeller made from reinforced materials, ensuring long service life even when handling fine sediment. The compact and slim design makes it the best choice for narrow manholes and confined working areas. The discharge outlet can be positioned vertically or inclined, helping prevent hose kinking and ensuring smooth water flow. APPLICATION • Construction sites – flat surface drainage, manholes, concrete preparation • Domestic & DIY – pools, terraces, flooded rooms • Agriculture & livestock – wash areas, tanks and small farm drainage • Emergency drainage in basements, garages and workshops MOTOR • Two-pole induction motor(n=2850 r.p.m) • Single-phase 230V/50Hz Model Power Q(m3/h) 0 1.3 2.4 3.5 4.8 6 7.2 8.5 9.7 10 Solids passage Connection (inch) kW HP Q(l/min) 0 20 40 60 80 100 120 140 160 170 Outlet H2Q SPA530 0.53 0.7 H (m) 11.4 10.8 10.2 9.5 8.8 8 7.2 6 4.2 8 6 mm 1" F Code Model Pump Packaging ØxH (mm) G.W .(kg) LxWxH (mm) B3.14.125 H2Q SPA530 Ø195x335 13.8 285x275x395 Components Construction Pump body: Steel Pump base: SS covered of wear resistant rubber Motor casing: Aluminium alloy casting Impeller: Thermoplastic Polyurethane (TPU)+AISI 201 SS insert Mechanical Seal Silicon Carbide OPERATING CONDITIONS • Liquid temperature up to 40°C • Max. immersion depth 5m SUBMERSIBLE PUMPS FLAT SUCTION SUBMERSIBLE PUMPS 20 40 60 80 100 120 140 160 180 200 220 3 6 12 9 7 13 20 26 H (ft) 33 Flow rate Q Head H (m) Equipped with 10 m cable and Schuko and 10 m rope
| H2Q catalogue 16 H2Q SSP SUBMERSIBLE PUMP The H2Q SSP 750 is a versatile and reliable submersible pump designed for clean water drainage in domestic and light duty applications. It ensures excellent corrosion resistance and long service life. Its compact size, low weight and ease of use make the SSP 750 a practical solution for homeowners, gardeners and hobby users who need efficient and trouble free clean water handling. APPLICATIONS • Domestic water drainage (basements, service rooms, tanks) • Garden irrigation and small landscape watering • Emptying of containers, reservoirs and small ponds • Water transfer for household systems and outdoor use • Light duty residential maintenance and hobby applications MOTOR • Two-pole induction motor (n = 2850 rpm) • Insulation Class B • Protection IP68 • Continuous duty S1 • Built-in thermal protector • Single-phase: 230 V / 50 Hz OPERATING CONDITIONS • Maximum immersion depth: 5 m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C Components Construction Pump body: AISI 304 SS Suction filter: AISI 304 SS Impeller: Techno-polymer Motor shaft: AISI 304 SS Mechanical seal: Ceramic / Graphite Model Power - Ampere Q(m3/h) 0 0.9 1.8 2.7 3.6 4.5 5.4 6.3 7.2 8.1 Solids passage Connection kW HP A Q(l/min) 0 15 30 45 60 75 90 105 120 135 Outlet (inch) H2Q SSP 750 AUTO 0.75 1 5 H (m) 7.5 6.6 6 5.5 4.8 4.2 3.5 2.8 2 1.2 5 mm 1" 1/4 Code Model N.W. (kg) LxWxH (mm) B3.13.650 H2Q SSP 750 AUTO 5.4 220×190×365 SUBMERSIBLE PUMPS CLEAN WATER SUBMERSIBLE PUMPS Equipped with 10 m cable and Schuko plug and float switch Flow rate Q Head H (m)
H2Q catalogue | 17 SUBMERSIBLE PUMPS SUBMERSIBLE WASTEWATER PUMPS H2Q 50TPS SUBMERSIBLE WASTEWATER PUMPS The H2Q 50TPS series consists of compact and corrosion resistant submersible pumps designed for the reliable transfer of clean water, dirty water and non aggressive wastewater. These pumps ensure a long service life and stable performance even in demanding residential or light industrial environments. The 50TPS-F version is equipped with a vertical float switch for fully automatic operation. APPLICATIONS • Drainage of clean or slightly dirty water in basements, garages and technical rooms • Emptying of tanks, pits, wells and small reservoirs • Handling of rainwater, infiltration water and industrial process water • Transfer of non aggressive wastewater in residential or light industrial systems • Emergency drainage in flooded areas • Automatic level control (50TPS F versions with float switch) MOTOR • Two-pole induction motor(n=2850 r.p.m) • Insulation Class B • Thermal protector for single-phase • Single-phase 230V/50Hz OPERATING CONDITIONS • Liquid temperature up to 40°C Code Model Description Pump Packaging N.W (kg) LxWxH (mm) G.W (kg) LxWxH (mm) B3.13.600 H2Q 50TPS-2.4F with vertical tube float 8.9 250x180x400 9.5 285x165x460 B3.13.602 H2Q 50TPS-2.4 without float 8.7 250x150x400 9.3 285x165x460 50TPS 50TPS-F Model Power Q(m3/h) 0 3 6 9 12 15 18 Solids passage Connection kW HP Q(l/min) 0 50 100 150 200 250 300 Outlet (Inch) H2Q 50TPS-2.4 0.4 0.5 H (m) 9.6 8.2 6.5 5 3.8 2.1 0.4 25 mm 2" H2Q 50TPS-2.4F 0.4 0.5 9.6 8.2 6.5 5 3.8 2.1 0.4 25 mm 2" Components Construction Pump casing: AISI304 SS Pump base: ABS plastic Motor shaft: AISI420 SS Impeller: PA+FG Equipped with 10 m cable and Schuko plug H(ft) 6 0 100 200 300 2 4 0 15 12 6 m3/h 8 10 0 5 10 20 60 30 L/min 50TPS 50 150 250 3 18 9 15 25 Flow rate Q Head H (m)
| H2Q catalogue 18 H2Q SWP SUBMERSIBLE SEWAGE PUMP The H2Q SWP 750 is a sturdy and reliable submersible pump designed for dirty water drainage in domestic environments. With a stainless steel AISI 304 body, it offers excellent corrosion resistance and long service life. The H2Q SWP 750 is suitable for discharging dirty water containing suspended solids up to 35 mm, making it ideal for cesspits, wastewater pits and general heavy domestic drainage. APPLICATIONS • Drainage of dirty water in basements, garages and service rooms • Emptying of cesspits and collection pits with solids up to 35 mm • Domestic wastewater and grey water discharge • Outdoor drainage in gardens, yards and flooded areas • Heavy domestic maintenance and general dirty water transfer MOTOR • Insulation Class B • Protection IP68 • Continuous duty S1 • Thermal protector for single-phase versions • Single-phase: 230 V / 50 Hz OPERATING CONDITIONS • Maximum immersion depth: 5 m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C Model Power - Ampere Q(m3/h) 0 1.2 2.4 3.6 4.8 6 7.2 8.4 9.6 10.8 Solids passage Connection kW HP A Q(l/min) 0 20 40 60 80 100 120 140 160 180 Outlet (inch) H2Q SWP 750 Auto 0.75 1 5 H (m) 8 7.6 7.2 6.7 6.2 5.7 5.1 4.5 3.9 3.2 35 mm 1"1/2 Code Model N.W. (kg) LxWxH (mm) B3.13.652 H2Q SWP 750 Auto 6.8 230x200x420 Components Construction Pump body: AISI 304 SS Impeller: AISI 304 SS Motor shaft: AISI 304 SS Mechanical seal: Ceramic/graphite SUBMERSIBLE PUMPS SUBMERSIBLE SEWAGE PUMPS Equipped with 10 m cable and Schuko plug and float switch Flow rate Q Head H (m)
H2Q catalogue | 19 H2Q MD VXP 4 IN 1 PUMPS WITH FLOAT The H2Q MD VXP is a highly versatile submersible pump equipped with a float switch and an innovative interchangeable base system that allows it to adapt to four different pumping configurations: • Flat suction mode (no base): drains water down to 1 mm, ideal for near dry finishing on flat surfaces. • Clean water mode (blue base): acts as a standard clean water pump with a 3 mm free passage, suitable for tanks, utility rooms and domestic drainage. • Dirty water mode (black base): transforms the pump into a wastewater unit capable of handling solids up to 30 mm, making it suitable for cesspits and outdoor drainage. • Continuous run mode: the float switch can be hooked into the dedicated slot on the handle, allowing uninterrupted operation when automatic start/stop is not required. The pump comes equipped with both bases, enabling instant adaptation to all applications. APPLICATIONS • Near dry drainage on flat surfaces, basements, technical rooms, terraces • Clean water drainage for tanks, storage containers and garden use • Wastewater removal from cesspits, wells and outdoor areas • Continuous pumping for controlled emptying or transfer • General domestic water transfer and emergency drainage MOTOR • Insulation class F • Protection class IPX8 • Single-phase: 230 V / 50 Hz Code Model N.W (Kg) Ø x H (mm)* G.W. (Kg) L x W x H (mm) B3.14.120 H2Q MD 500 VXP 3.9 Ø 175x325 4.5 199x198x356 B3.14.124 H2Q MD 900 VXP 4.70 Ø 175x325 5.3 199x198x356 SUBMERSIBLE PUMPS SUBMERSIBLE SEWAGE PUMPS Components Construction Pump body: PP+GF30 Impeller: PA+GF30 Motor shaft: Carbon steel black rust prevention process No. Model Power Q(m3/h) 0 2 4 6 8 10 12 14 15.2 Solids passage Connection kW HP Q(l/min) 0 33 66 100 133 167 200 234 390 Outlet (inch) A H2Q MD 500 VXP 0.5 0.7 H (m) 6.5 5 3.8 2.9 1.8 0.8 from 1 to 30 mm 1" - 1" 1/4 - 1" 1/2 B H2Q MD 900 VXP 0.9 1.2 9 7.2 6.5 6 5.4 4.5 3.2 2.1 1.6 1" - 1" 1/4 - 1" 1/2 Flow rate Q Head H (m) 1 2 3 4 5 6 7 8 9 10 0 33 66 100 133 167 200 234 267 2 4 6 8 10 12 14 16 l/min m3/h 0 10 20 30 5 15 H(ft) 25 MD VXP A B *dimensions with hose connection mm 245x175x325 OPERATING CONDITIONS • Maximum immersion depth: 7 m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C Ø H Equipped with 10 m cable and Schuko plug
| H2Q catalogue 20 SUBMERSIBLE PUMPS SUBMERSIBLE SEWAGE PUMPS H2Q Q750B SUBMERSIBLE PUMP WITH BUILT-IN SENSOR The H2Q Q750B is a compact and robust submersible pump designed for dirty-water drainage in residential environments. Powered by a durable motor and equipped with triple sealing and an oil filled chamber, it ensures dependable performance and a long service life. Its lightweight design and easy handling make it ideal for everyday domestic water removal tasks. The pump starts pumping at a water level of 100 mm and automatically stops at 42 mm. A standout feature of this model is the integrated Aquasensor electronic control system, which replaces traditional mechanical float switches with precise water level detection supported by LED indicators. The Aquasensor allows the user to select exact start and stop levels, ensuring accurate activation even in narrow spaces where a float cannot operate. In addition, the Aquasensor offers advanced delayed stop modes of 10 and 20 minutes, selectable directly from the control panel. These allow the pump to continue running after the water level falls below the stop point, ensuring complete drainage and preventing residual water accumulation—especially useful in basements and collection pits. APPLICATIONS • Automatic basement and pit drainage, even with dirty water • Emptying of cisterns, tanks, ponds and open wells • Domestic water removal in utility rooms and collection pits • Hands free operation in narrow spaces MOTOR • Two-pole induction motor(n=2850 r.p.m) • Protection IPX8 • Single-phase 230V/50Hz Flow rate Q Head H (m) Model Power Q(m3/h) 0 33 67 100 133 166 200 233 267 290 Solids passage Connection kW HP Q(l/min) 0 2 4 6 8 10 12 14 1617.5 Outlet (inch) H2Q Q750B 0.75 1 H (m) 8,8 8.2 8 7.8 6.4 5.4 4.1 2.6 1.2 0 35 mm 1" - 1" 1/2 Code Model Pump Packaging N.W. (kg) LxWxH (mm) G.W. (kg) LxWxH (mm) A3.02.250 H2Q Q750B 5.58 237x172x352 5.94 270x230x420 Components Construction Pump body: PP - GF30 Motor winding: Aluminum Impeller: PA66 - GF30 Motor shaft: Carbon Steel OPERATING CONDITIONS • Liquid temperature up to 35°C • Max. immersion depth 7m Equipped with 10 m cable and Schuko plug 0 2 4 6 8 10 12 14 1 2 3 4 5 6 7 8 9 0 0 33 H(ft) m3/h l/min 67 100 133 166 200 233 3 6 10 13 16 20 23 26 30 16 18 267 300 Q750B
H2Q catalogue | 21 No. Model Power - Ampere Q(m3/h) 0 6 12 18 24 30 36 Solids passage Connection kW HP A Q(l/min) 0 100 200 300 400 500 600 Outlet (inch) A H2Q CSP 750 0.75 1 5.5 H (m) 10.5 8.7 6.8 4.8 2 35 mm 2" B H2Q CSP 1100 1.1 1.5 7.6 13 11 9.5 7.5 5.5 2.5 35 mm 2" C H2Q CSP 1500 1.5 2 10.5 15 13 12 10.5 8.5 6.5 3 35 mm 2" Code Model G.W. (kg) LxWxH (mm) B3.13.400 H2Q CSP 750 17.5 285×198×485 B3.13.402 H2Q CSP 1100 19.5 285×198×500 B3.13.404 H2Q CSP 1500 21.5 285×198×520 SUBMERSIBLE PUMPS SUBMERSIBLE SEWAGE PUMPS Components Construction Pump body: Cast iron Motor housing: AISI 201 SS Impeller: Cast iron Motor shaft: AISI 304 SS Mechanical seal: Silicon carbide / Silicon carbide (SiC/SiC) H2Q CSP SUBMERSIBLE SEWAGE PUMPS The H2Q CSP series consists of robust and reliable submersible pumps designed for the continuous drainage of non chemically aggressive dirty water. Their heavy duty construction ensures excellent durability, corrosion resistance and long operating life, even in demanding conditions. The CSP pumps are capable of handling suspended solids up to 35 mm. APPLICATIONS • Drainage of dirty water in basements, garages and utility rooms • Emptying of cesspits and wastewater collection pits containing solids up to 35 mm • Removal of non aggressive domestic wastewater and grey water • Cleaning and drainage of tanks, reservoirs and flooded outdoor areas • Heavy duty dirty water transfer for residential maintenance and service tasks MOTOR • Two-pole induction motor (n = 2850 rpm) • Insulation class B • Protection class IP68 • Continuous duty S1 • Thermal protector for single-phase versions • Single-phase: 230 V / 50 Hz OPERATING CONDITIONS • Maximum immersion depth: 5m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C A B C Flow rate Q Head H (m) Single-phase models equipped with 10 m cable and Schuko plug and float switch
| H2Q catalogue 22 H2Q SSW SUBMERSIBLE SEWAGE PUMPS The H2Q SSW series comprises heavy duty submersible pumps designed for the reliable lifting and drainage of loaded wastewater in domestic environments. Fully built in AISI 304 stainless steel, the SSW range offers excellent corrosion resistance, long service life and dependable operation even under demanding conditions. Thanks to their vortex impeller design, the SSW pumps are capable of handling suspended solids up to 45 mm. APPLICATION • Drainage of dirty water in basements, garages and technical rooms • Emptying of cesspits and wastewater wells containing solids up to 45 mm • Removal of grey water and non chemically aggressive domestic wastewater • Cleaning and drainage of tanks, reservoirs and outdoor flooded areas • Heavy duty wastewater transfer for residential maintenance and service tasks MOTOR • Two-pole induction motor (n = 2850 rpm) • Insulation Class B • Protection IP68 • Continuous duty S1 • Thermal protector for single-phase • Single-phase: 230 V / 50 Hz • Three-phase: 400 V / 50 Hz No. Model Power - Ampere Q(m3/h) 0 3 6 9 12 15 18 21 24 27 Solids passage Connection kW HP 1x230V 3x400V Q(l/min) 0 50 100 150 200 250 300 350 400 450 Outlet (inch) A H2Q SSW 750 0.75 1 4.1 1.5 H (m) 11 10 9 8 6.5 5 45 mm 1" 1/2 B H2Q SSW 1100 1.1 1.5 5.5 2.3 12.5 11.5 10.5 9.5 8.5 7 5.5 4 2.5 45 mm 2" C H2Q SSW 1500 1.5 2 6.2 2.5 15 13.7 13 12 10.8 9.5 8 6.5 4.5 2.5 45 mm 2" Code Model N.W. (kg) LxWxH (mm) B3.13.660 H2Q SSW 750 3x400 12 260×260×505 B3.13.662 H2Q SSW 750 1x230 Auto 12 260×260×505 B3.13.664 H2Q SSW 1100 3x400 13 275×275×520 B3.13.666 H2Q SSW 1100 1x230 Auto 13 275×275×520 B3.13.668 H2Q SSW 1500 3x400 15 275×275×550 B3.13.670 H2Q SSW 1500 1x230 Auto 15 275×275×550 Components Construction Pump body: AISI 304 SS Motor housing: AISI 304SS Impeller: AISI 304 SS Motor shaft: AISI 304 SS Mechanical seal: Silicon carbide / Silicon carbide (SiC/SiC) SUBMERSIBLE PUMPS SUBMERSIBLE SEWAGE PUMPS Single-phase models equipped with 10 m cable and Schuko plug OPERATING CONDITIONS • Maximum immersion depth: 5 m • Liquid temperature: up to 35 °C • Maximum ambient temperature: 40 °C Auto-models with float switch
H2Q catalogue | 23 H2Q SP530 CONSTRUCTION SITE SUBMERSIBLE PUMPS The H2Q SP530 series is a range of portable submersible drainage pumps designed for fast and reliable clean water removal in domestic and light construction environments. Although compact and easy to handle, the SP530 pumps deliver durability and performance comparable to higher grade site dewatering units, thanks to the use of abrasion resistant materials and a heavy duty motor structure. The SP530 range adopts a top discharge, flow thru cooling design, which provides maximum motor cooling efficiency and allows continuous operation even at low water levels, extending motor life and ensuring stable performance. The discharge outlet can be positioned vertically or inclined, helping prevent hose kinking and ensuring smooth water flow. The SP530A version integrates a float switch for automatic level control, making it suitable for unattended operation in continuous duty cycles. APPLICATION • Drainage of clean or slightly dirty water in basements, garages and utility rooms • Emptying of tanks, pits, containers and small reservoirs • Water removal from construction sites, maintenance areas and narrow shafts • Garden and landscape drainage or light irrigation tasks • Automatic water level control (SP530A) MOTOR • Two-pole induction motor(n=2850 r.p.m) • Single-phase 230V/50Hz Code Model Pump Packaging ØxH (mm) G.W. (kg) LxWxH (mm) B3.14.126 H2Q SP530 Ø185x305 13 220x220x340 B3.14.127 H2Q SP530A Ø185x305 13 220x220x340 SUBMERSIBLE PUMPS CONSTRUCTION SITE SUBMERSIBLE PUMPS 7 13 20 26 H (ft) 33 25 50 75 100 125 150 175 200 225 250 275 . Flow rate Q Head H (m) SP530 SP530A Components Construction Pump body: Steel Pump base: SS covered of wear resistant rubber Motor casing: Aluminium alloy casting Impeller: Thermoplastic Polyurethane (TPU)+AISI 201 SS insert Mechanical Seal Silicon Carbide double in oil bath OPERATING CONDITIONS • Liquid temperature up to 40°C • Max. immersion depth 5m Model Power Q(m3/h) 0 1.5 3 4.5 6 7.5 9 10.5 12 13.5 15 Solid passage Connection kW HP Q(l/min) 0 25 50 75 100 125 150 175 200 225 250 Outlet (inch) H2Q SP530 0.53 0.7 H (m) 11 10.3 9.8 9.1 8.5 7.8 7 6.2 5 3.7 2.2 6 mm 2" H2Q SP530A 0.53 0.7 11 10.3 9.8 9.1 8.5 7.8 7 6.2 5 3.7 2.2 6 mm 2" Equipped with 10 m cable and Schuko and 10 m rope
| H2Q catalogue 24 H2Q CCS SUBMERSIBLE PUMPS WITH AGITATOR The H2Q CCS series consists of compact and durable submersible pumps designed for handling clean water, slightly dirty water, sewage and non aggressive industrial wastewater. A defining feature of the CCS series is the agitator mounted on the extended motor shaft whose action ensures continuous mixing of the liquid, allowing suspended solids to be carried smoothly during pumping operations. For added stability and vibration reduction, these pumps feature a rubber base that improves traction on the bottom surface and ensures consistent performance even in muddy or uneven areas APPLICATIONS • Construction site drainage • Drainage of dirty water, grey water and non aggressive wastewater • Pumping of muddy water, sludge and sediment laden pits • Emptying of wells, sumps and collection chambers with solid deposits • Cleaning of basins and pits • Water handling in agricultural, workshop and industrial areas • Construction site drainage and wash down operations MOTOR • Two-pole induction motor(n=2850 r.p.m) • Single-phase 230V/50Hz • Insulation Class B for CCS400 series • Insulation Class F for CCS750 series • Thermal protector for single-phase versions Code Model Pump Packaging N.W. (kg) LxWxH (mm) G.W. (kg) LxWxH (mm) B3.14.140 H2Q CCS 400 13.3 240x200x400 14 250x205x440 B3.14.141 H2Q CCS 400A 13.5 240x200x400 14.2 250x205x440 B3.14.142 H2Q CCS 750 14.7 240x200x410 15.4 250x205x440 B3.14.143 H2Q CCS 750A 15 240x200x410 15.6 250x205x440 SUBMERSIBLE PUMPS CONSTRUCTION SITE SUBMERSIBLE PUMPS Components Construction Pump casing: AISI304 SS Pump base: PVC Rubber Motor shaft: AISI420 SS Shaft Seal: Silicon Carbide Impeller: CCS400: PA+FG CCS750: PA+FG with steel plate OPERATING CONDITIONS • Liquid temperature up to 40°C No. Model Power - Ampere Q(m3/h) 0 50 100 150 200 250 300 Solids passage Connection kW HP A Q(l/min) 0 3 6 9 12 15 18 Outlet (inch) A H2Q CCS 400 0.4 0.55 2.7 H (m) 12 10 7.5 4 1 7 mm 2" B H2Q CCS 750 0.75 1 5 16 14 12 9.8 7 4 0.6 7 mm 2" "A" model with float switch H(ft) 9 0 100 200 300 3 0 6 0 18 12 6 m3/h 12 15 18 0 30 10 20 40 60 50 L/min CCS 50 150 250 15 9 3 A B Flow rate Q Head H (m)
